LuminaMap 3D Visualizer

Next-generation hardware-accelerated 3D projection warping engine with real-time laser vector calculation.

Graphics API Vulkan 1.3 / DirectX 12 Ultimate
Output Capacity Up to 16x 4K @ 120Hz Displays
Camera Tracking FreeD, OptiTrack, BlackTraX
Reference Protocol Vulkan Khronos Standard →
LuminaMap 3D Laser Volumetric Visualizer

Dynamic Mesh Warping & Laser Alignment

LuminaMap 3D changes how visual designers interact with non-planar projection surfaces. By importing OBJ/FBX CAD designs or pulling live LiDAR spatial scans from stage cameras, LuminaMap dynamically warps pixel grids onto complex 3D objects with sub-millimeter precision.

Core Technical Features

  • LiDAR Point-Cloud Auto-Alignment: Matches projector output to physical stage geometry automatically using infrared sensor feedback loops.
  • Volumetric Beam Raytracing: Accurately simulates particulate atmospheric haze density and laser light scattering before deploying physically to the stage.
  • Low-Latency NDI & SDI Pipeline: Native hardware video ingest via Blackmagic DeckLink and NDI 6 ultra-HD video feeds.

System Requirements

Requires an enterprise workstation with NVIDIA RTX 6000 Ada or dual RTX 4090 GPUs, 64GB DDR5 RAM, and high-speed NVMe RAID arrays for uncompressed 4K video playback.
